Delta®

Codo de pared cuadrado para ducha manual en negro mate

N.º de modelo: 50570-BL
Agregar a favoritos
Busque instaladores locales de Delta®
Delta®
Codo de pared cuadrado para ducha manual en negro mate
N.º de modelo: 50570-BL
Precio de lista: $9405
Agregar a favoritos
Busque instaladores locales de Delta®
CARACTERÍSTICAS DEL PRODUCTO
Este codo de pared cuadrado para duchas manuales ofrece una solución elegante para su ducha personalizada. El negro mate da personalidad a su espacio, genera un aire sofisticado y combina perfectamente con casi todos los demás detalles y accesorios. Con tonos brillantes, el negro mate es innegablemente moderno con un fuerte contraste, pero también puede complementar espacios tradicionales o de transición cuando se combina con colores neutros cálidos para brindar una sensación rústica similar al hierro fundido. Pieza de repuesto original de Delta.
  • Acabado negro mate.
  • Pieza de repuesto original de Delta.
  • Dimensiones generales del producto: 2 1/8" de alto x 1 1/16" de profundidad x 2 1/8" de ancho.
  • Diseño cuadrado con un aspecto más moderno.
Documentos y especificaciones
Soporte para productos, repuestos y especificaciones técnicas
Ver especificaciones técnicas
Ver hoja de mantenimiento e instalación
Registrar su producto
Información de instalación
Overall Height (in.) :
2 1/8
Voltaje:
0
Tipo de válvula:
NA

SOPORTE PARA LA INSTALACIÓN

¿Necesita ayuda con la instalación? Busque instaladores locales de Delta® Obtenga cotizaciones. Lea reseñas.

IR
Escriba un código postal válido.
Mike y Hanna
Miniatura del logotipo de Delta

¿Necesita ayuda con la instalación? ¡Mike y Hannah están aquí para ayudar! Reciba consejos de los profesionales para todo, desde la instalación hasta el cuidado del producto.

Explorar videos
RESEÑAS
Rated 1 out of 5 by from Dumb design Should have just designed this where it comes out from the pipe where the shower head is or at least this option for small showers.
Date published: 2024-10-02
Rated 5 out of 5 by from Quality item Nice and heavy. Finish is very good.
Date published: 2024-08-28
Rated 5 out of 5 by from Excellent As described, stylish easy to install
Date published: 2024-04-16
Rated 5 out of 5 by from No or No problem with this part
Date published: 2023-10-15
Rated 5 out of 5 by from Delta brand I would buy nothing but Delta brand
Date published: 2023-09-27
Rated 5 out of 5 by from Excellent quality This item woks as intended so far.
Date published: 2023-09-16
Rated 5 out of 5 by from Nice look Sleek design
Date published: 2023-05-16
Rated 5 out of 5 by from Handle Works good looks good fast delivery
Date published: 2022-12-17
  • y_2024, m_11, d_21, h_6
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.42
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_63
  • loc_en_US, sid_50570-BL, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_deltafaucet
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 6ms
  • reviews, product
Preguntas y respuestas

I knicked the paint installing, is there black touch paint I can get?

Asked by: Gwarr73
Hello Gwarr73, Thank you for your question regarding the Delta Square Wall Elbow for Hand Shower and I am happy to assist you today. Unfortunately, we do not manufacture touch-up paint for our accessories, nor do we have any recommendations at this time and I apologize for any inconvenience this may cause. It may be best to look into companies that carry repair and coloring kits, similar to Multi-Tech Products to see if they may carry a touch-up paint to match the Matte Black finish. I hope this is helpful and I am sorry I couldn't assist you further with this issue. Please feel free to give us a call if we can help you with anything else going forward at 800-345-3358. Thank you, Brandy Delta Faucet Company Customer Service
Answered by: Brandy
Date published: 2024-03-28

What does this look like installed? Does the black gasket show or is it recessed ?

Asked by: Jb
Hi JB, Thank you for your question. When installed, model 50570 looks exactly as it does in the picture provided. The black gasket will show once it is installed. Best Regards, Courtney
Answered by: DeltaFaucet12
Date published: 2024-03-28

What material nipple should be used?

What type of metal should be used for the nipple (brass, black steel, etc.) where's a good place to get it from also?
Asked by: Andrew T.
Dear Andrew T, Thank you for your question. To install the Delta Square Wall Elbow for Hand Shower 50570-SS, you would need 1/2" copper or galvanized pipe. The nipple should extend past the finished wall no more than 3/16" (4.8 mm) and no less than 1/16" (1.6 mm). You would want to check with your local plumbing dealer for these types of pipes. https://media.deltafaucet.com/MandI/68432%20Rev%20A.pdf Best regards, Tanya
Answered by: Tanya
Date published: 2016-10-24

Is there any reason this cannot be installed without the gasket?

The wall tile it will be installed on is textured and wouldn't provide a water tight seal anyways. So, is there any harm in installing without the gasket and adding a bead of silicone? I need to do this because the required nipple length is in between 1/2" sizes and I need the extra 1/8" of threading to get a good seal.
Asked by: Kevin
Hi Kevin, Thank you for your question. We recommend using the gasket as it helps to protect the wall during installation as well. You may use a bead of silicone to help provide a water tight seal. Best regards, Jon
Answered by: DeltaFaucet3
Date published: 2024-03-28

Do you have wall elbow square with 3/4 female inlet and 1/2 male outlet ?

Asked by: STEPHEN
Hi, Stephen! Thank you for your question. At this time, we only make wall elbows with 1/2" connections for both male outlets and female inlets. We do apologize for any inconvenience this may cause. Best Regards, Rosanna
Answered by: Delta Faucet
Date published: 2024-03-28

How high from the floor would I mount the elbow and how far from the floor should the bottom of the shower bar be installed? Thank you.

Asked by: Dale
Hi, Dale! Thank you for your question. We do not have a recommended measurement for the Delta 50570-SS Wall Elbow from the floor or the shower bar. We leave this measurement up to the end user for their own custom shower convenience. Best Regards, Rosanna
Answered by: DeltaFaucet11
Date published: 2024-03-28

why are there 2 lines? your catalog shows 1 line

Asked by: long ball
Hi Long Ball, Thank you for your question. The 1/2" IPS female inlet is where the wall elbow attaches to the supply line in the wall. The 1/2" IPS male outlet is where the single hose attaches. Thanks, Dave
Answered by: DeltaFaucet2
Date published: 2024-03-28

1/2" pipe nipple length

Hello, My 1/2" pipe nipple extends 1/4" from the finished surface. At this point, I'm not able to replace the pipe nipple. Is there any kind of extension or additional gasket that I can install. Thanks,
Asked by: Dan
Hi Dan, Thank you for your question. Unfortunately we do not offer an extension or gasket to solve your issue of the pipe nipple extending too far from the wall. You may be able to use caulk to make up the 1/16" difference in depth if you cannot change the nipple. Thanks, Dave
Answered by: DeltaFaucet2
Date published: 2024-03-28
