Delta®

Manija - Manija gris/dial de temperatura - Monitor®

N.º de modelo: RP16202
Agregar a favoritos
Busque instaladores locales de Delta®
Delta®
Manija - Manija gris/dial de temperatura - Monitor®
N.º de modelo: RP16202
Precio de lista: $18.30
Precio en línea: $13.96
Free Ground Shipping All Orders $49+
Agregar a favoritos
Busque instaladores locales de Delta®
Documentos y especificaciones
Información de instalación
Overall Height (in.) :
1 1/16
Tipo de válvula:
NA
RESEÑAS
Rated 5 out of 5 by from Delta Faucet Ring Got it fast, works just like the old ugly one did. Looks great
Date published: 2013-08-01
Rated 5 out of 5 by from delta replacement part Had a hard time finding this part to fix a delta shower faucet that is about 14 years old. Found it here, removed old one put on this new one and we are showering again.
Date published: 2011-05-04
  • y_2025, m_6, d_17, h_4
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.42
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_2
  • loc_en_US, sid_RP16202, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_deltafaucet
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 6ms
  • reviews, product
Preguntas y respuestas

Conversion Valve for this unit

I have the 1500/1700 series faucet with Cartridge RP32104 that I read on here. The brown Hot/Cold portion is VERY hard to turn now and I think caused the brown portion of the plastic adjustment handle to break, RP 16202. Can I lube this inner turning valve portion to prevent this? OR... I would like to Replace it with a regular basic single handle turning lever and Cartridge. What Cartridge and handle assy can I use to do this without having to replace the entire valve unit. Thanks. Read more: http://www.deltafaucet.com/repairparts/details/rp16202.html#ixzz3Tx1rercx
Asked by: YurHandyman
Hi YurHandyman, We are sorry that you are experiencing a problem with your 1500 series faucet. If the temperature handle becomes difficult to move the issue is most likely the RP32104 cartridge which will need to be replaced. The RP32104 will come pre-lubed. If you damaged the RP16202 temperature knob that will need to be replaced as well. Unfortunately it is not possible to convert your 1500 series faucet to a basic single handle turning lever without changing the rough in valve. Thanks, Dave
Answered by: DeltaFaucet2
Date published: 2024-03-28

will this fix my problem

I have a Delta Monitor Shower Faucet & the temperature control knob often gets stuck resulting in not being able to adjust the temperature. What do you think is the problem? I do not have the model # but attached a photo.
Asked by: Karen Slack
Hi Karen, Thank you for your question. If you did not have prior trouble with the temperature knob then the likely issue is the cartridgge, not the handle. The replacement cartridge for your 1500 series faucet is RP32104. Thanks, Dave
Answered by: DeltaFaucet2
Date published: 2024-03-28

Index Button

Are replacement index buttons available for RP162012?
Asked by: Harold Fox
Hi Harold, Thank you for your question. The RP16201 is the button that goes on the RP16202 temperature handle. You can order this online at deltafaucet.com. Here is the link: http://www.deltafaucet.com/repairparts/details/rp16201.html?showPhotoGallery=false Thanks, Dave
Answered by: DeltaFaucet2
Date published: 2024-03-28

Do they sell a stainless trim kit for the Monitor 1500? I can't find a list of parts for this model.

Asked by: wolfcooper
Thank you for your question, wolfcooper! If the screws on the escutcheon plate are at 1 o'clock & 7 o'clock, you can install a Monitor 17 Series trim kit using the RP32104 cartridge (sold separately). https://www.deltafaucet.com/bathroom/showering/tub-and-shower-faucets?ValveType=Dual-function+pressure+balance+cartridge Unfortunately, if the screws are at 5 & 7 o'clock on the plate, there are no trim kits available. The valve would need to be replaced with a MultiChoice R10000 valve in order to install a new trim kit. Best regards, Jon
Answered by: DeltaFaucet3
Date published: 2024-03-28

Is this the temperature control for the older model?

Asked by: John
Hi John, Thank you for reaching out to Delta Faucet Company! Our RP16202 is used with our 1500 tub/shower series. It is the temperature cap that fits the old handle and cartridge. We appreciate your inquiry. Please reach out directly if you have further questions! Best Regards, Kyra Digital Engagement Specialist
Answered by: Customer Service
Date published: 2024-01-31

Does the crest hot cold on the other side come with it,is not what is the part # ,thank you. Daniel.

Asked by: Dan550
Hi Dan550, Thank you for contacting Delta Faucet Company! We apologize for the issues you are experiencing and we are happy to help! We have reached out to you directly to further assist you with this matter. We appreciate your inquiry. Please reach out directly if you have further questions! Best Regards, Kyra Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-06-13
