DELTA
Single Handle Tub and Shower in Chrome
N.º de modelo: B114915C
Image Thumbnail, click to view zoomed product image
nulo
nulo
nulo
nulo
nulo
nulo
nulo
nulo
nulo
nulo
- CARACTERÍSTICAS DEL PRODUCTO
- Documentos y especificaciones
- RESEÑAS
- Preguntas y respuestas
- LISTA DE PIEZAS
CARACTERÍSTICAS DEL PRODUCTO
Información especial
ADVERTENCIA de la Proposición 65 de California
ADVERTENCIA DE LA PROPOSICIÓN 65 de California
Este producto puede exponerle al plomo, que según el estado de California causa cáncer y anomalías congénitas u otros daños reproductivos.
Para obtener más información, visite http://www.P65Warnings.ca.gov.
Ecológica
Con etiqueta WaterSense®
Technology and Special Features
Cumplimiento con la ADA
Cumplimiento con la ADA
Algunas personas y códigos locales requieren que los artefactos cumplan con la Ley para estadounidenses con discapacidades (Americans with Disabilities Act). Si es posible que reciba visitas de personas con capacidades especiales o si cree que sus futuros clientes podrían apreciar esta función, Delta ofrece diversos artefactos que cumplen con esta ley.
Documentos y especificaciones
Soporte para productos, repuestos y especificaciones técnicas
Información de instalación
Overall Height (in.) :
16 1/4
Voltaje:
0
Caudal:
1.75 gpm a 80 psi, 6.6 l/min. a 552 kPa
Tipo de válvula:
Cartucho con equilibrio de presión de función única
SOPORTE PARA LA INSTALACIÓN
¿Necesita ayuda con la instalación? Busque instaladores locales de Delta® Obtenga cotizaciones. Lea reseñas.
¿Necesita ayuda con la instalación? ¡Mike y Hannah están aquí para ayudar! Reciba consejos de los profesionales para todo, desde la instalación hasta el cuidado del producto.
LISTA DE PIEZAS
LISTA DE PIEZAS
View Product
![Image-Master-RP74149]()
Foundations®
Foundations® Escutcheon - Shower
Precio de lista: $47.35 - $68.35
Acabados estándar
RP74149
View Product
![Image-RP79243]()
Foundations®
Foundations® Set Screw - Handle - Tub & Shower
Precio de lista: $8.90
Precio en línea: $7.12
Free Ground Shipping All Orders $49+
Acabados estándar
RP79243
2.67 3
View Product
![Image-Master-RP6025PR]()
Delta®
Delta® Brida - Ducha
Precio de lista: $19.30 - $35.40
Free Ground Shipping All Orders $49+
Acabados Lumicoat
Acabados estándar
RP6025PR
View Product
![Image-Master-RP6023PR]()
Dryden®
Dryden® Shower Arm
Precio de lista: $36.50 - $91.60
Free Ground Shipping All Orders $49+
Acabados Lumicoat
Acabados estándar
RP6023PR
View Product
![Image-Master-RP64721]()
Foundations®
Foundations® Tubo de salida para bañera - Desviador con tirador hacia arriba
Precio de lista: $64.95 - $97.10
Free Ground Shipping All Orders $49+
Acabados estándar
RP64721
View Product
![Image-Master-RP74148]()
Foundations®
Foundations® Metal Lever Handle Kit - Tub & Shower
Precio de lista: $51.70 - $66.60
Free Ground Shipping All Orders $49+
Acabados estándar
RP74148
RESEÑAS
Rated 3 out of
5
by
William from
Worked
I like this product. I have had issues getting the cartridge replaced as it's no longer functioning.
Date published: 2019-07-23
Rated 1 out of
5
by
Frustrated from
Having issue
Bought this for a remodel, have it all plumbed and ready to go, and the when I turn on the supply valves, the valve doesn’t turn the water off. No idea what the heck is going on
Date published: 2019-06-02
Rated 5 out of
5
by
Granny j from
Looks great!!
Love the looks and ease to use!!!
Date published: 2019-03-02
Rated 5 out of
5
by
tom073 from
Nice
so far so good Like the way it works
Date published: 2019-01-30
Rated 3 out of
5
by
Weazul from
Works as it should
This faucet works good but the water saving feature does not let us have as much pressure as with the old one.
Date published: 2019-01-26
Rated 5 out of
5
by
Monty from
Excellent quality
Easy installation and it works wonderfully!! Looks amazing as well.
Date published: 2018-10-29
Rated 5 out of
5
by
susie from
Love appearance but not crazy on the shower head.
Purchased for our remodeling. The bathtub faucet flow is great but the shower head just dribbled out. Called Delta and they are sending another one. They explained that the part where you turn water on and off may be put in backwards. We are going to check with plumbers and we will see what has happened. At least we will have another to replace the one we have if something is wrong with it. This is for our extra bath so we did not need one that flowed that fast but we would like it to be a little stronger.
Date published: 2018-06-30
Rated 5 out of
5
by
Mick from
Works great.
Best investment I made. The product is the best on the market.
Date published: 2017-10-25
Rated 4 out of
5
by
Samuelongo from
Clean bathroom remodel. easy to use.
having trouble adjusting hot water stop ring. And it seems center philips head screw is too short and not enough treads are engaging to keep handle from wobbling a bit. Also installer had to file the plastic stop ring a little to get more hot water to flow. Anything wrong with that?
One more thing is the water suppose to come out of the shower head after turning water off and for how long? Mine will flow some water for a few seconds then stop. Then after a few minutes a little more water will flow then stop. Then flow a little more then stop. Until eventually it will stop completely. This on off water flow takes about 2-5min to stop. This may or may not be normal due to the water still in the pipe after the valve, but why does it do this in cycles on-off and not all at once?
Date published: 2017-08-16
Preguntas y respuestas
Can I weld my copper pipe inside the manifold
Hi, Chris.
Thank you for your question. We do not recommend welding the copper pipe inside the manifold for the Delta B114915C Tub and Shower Unit. We recommend reading the instructions before installing. Here is a link to the Maintenance & Installation Sheet for the faucet:
https://media.deltafaucet.com/MandI/101650%20Rev%20B.pdf
Best Regards,
Rosanna
Date published: 2024-03-28
Does the cartridge come with it. If not, which cartridge ?
Hi, Phyllis!
Thank you for your question. The Delta B114915C does include the RP70538 Valve Cartridge Assembly.
Best Regards,
Rosanna
Date published: 2024-03-28
How to increase more hot water please sand me video
Hello Jimmy Patel,
Thank you for your question. Unfortunately, we do not have a video for adjusting the limit stop on the Delta Foundations Shower B114915C faucet model. However, to adjust the limit stop: First, remove the handle and adapter nut on the faucet and set them aside. You will now see a small black o-ring on the end of the brass stem. Remove this o-ring and again set aside. The next piece is the limit stop, you may see the words hot/cold. Rotate this part clockwise for hotter water. Each notch you move the piece, it will increase the maximum hot water by approximately 2-3 degrees. Reinstall the o-ring, adapter and handle. Please see page 7 of the instructions linked below.
https://media.deltafaucet.com/MandI/88723%20Rev%20A.pdf
Best regards,
Tanya
Date published: 2024-03-28
i installed a new shower control and faucet but the water pours out of shower head when running a bath. water pressure is at 35 lbs
Hello Brian White,
Thank you for your question. Based on your description of the flow from the tub/shower, you are experiencing an issue known as shower rise. This is an installation issue, which has several possible causes:
The valve could be upside down.
The length from the valve to the tub spout is outside of the 8" to 18" rule.
There is more than one 90-degree angle elbow.
Something other than ½" smooth copper or galvanized pipe was used going to the spout. No push fittings. No "shark-bite" fittings. No cast or drop ear elbows.
Something restricting the water flow to the spout, e.g. solder or something lodged in the pipe. If this is the cause of shower-rise it is possible to remove the blockage by removing the tub spout; then, feeding a plumber’s snake or a speedometer cable up through the tub drop. The act of feeding it causes it to twirl and loosen the blockage. Be sure to flush the valve before reinstalling the tub spout. Be sure to check the tub spout itself for blockage.
Please feel free to call, email, or message us on social if there is anything else you need.
Best regards,
Tanya
Phone: 1-800-345-3358 | Email: customerservice@deltafaucet.com | Facebook/Twitter: @deltafaucet
Date published: 2024-03-28
how to adjust water flow
Hi, Glenn!
Thank you for your question. The Delta B114915C Tub and Shower Unit does not have an adjustment for water flow. The volume for the unit only comes on at full volume.
Best Regards,
Rosanna
Date published: 2024-03-28
send instruction to ajust temerature to hotter water
Hi, Will!
Thank you for your question. Here is a link to the Maintenance and Instruction Guide for the Delta B114915C Faucet to show how to adjust the rotational limit stop on page 7:
https://media.deltafaucet.com/MandI/101650%20Rev%20B.pdf
Best Regards, Rosanna
Date published: 2024-03-28
can I get Polished brass trim (faceplate escutcheon and handle) for this valve?
Hi, Thank you for your question. I do apologize for any confusion regarding your Delta product. We are happy to help!
We are sorry, we do not have this model B114915C-SS in the polished brass finish.
Please contact us at 1-800-345-3358 if you have any further concerns. We are open Monday through Friday 7:00 AM to 7:00 PM central time, and 8:00 AM to 5:00 PM on Saturday.
Best Regards,
Bethany
Date published: 2024-03-28
What is the replacement cartridge kit part number for this? I have one that I bought at Menards and it's no longer putting out any hot water. Would like to get the part locally rather than order online.
Dear Asker Beneb,
Thank you for your question, I will be more than happy to help you with this. The cartridge is part RP70538. If you need further assistance, please contact us directly.
Best Regards, Samantha
Phone: 1-800-345-3358 | Email: customerservice@deltafaucet.com
Date published: 2024-03-28
Información especial
ADVERTENCIA de la Proposición 65 de California
ADVERTENCIA DE LA PROPOSICIÓN 65 de California
Este producto puede exponerle al plomo, que según el estado de California causa cáncer y anomalías congénitas u otros daños reproductivos.
Para obtener más información, visite http://www.P65Warnings.ca.gov.
