Ashlyn®
Ver toda la colección para baño Ashlyn®

Monitor® 14 Series Shower Trim - Less Head in Chrome

N.º de modelo: T14264-LHD
Agregar a favoritos
Busque instaladores locales de Delta®
Ashlyn®
Ver toda la colección para baño Ashlyn®
Monitor® 14 Series Shower Trim - Less Head in Chrome
N.º de modelo: T14264-LHD
Precio de lista: $15090
Agregar a favoritos
Busque instaladores locales de Delta®
CARACTERÍSTICAS DEL PRODUCTO
Las válvulas de equilibrio de presión de Delta® usan la tecnología Monitor® para protegerlos a usted y a su familia de los cambios repentinos de temperatura. El cromado se ha convertido rápidamente en uno de los acabados más populares en todos los estilos de decoración de baño gracias a su impactante brillo y versatilidad natural. Combinado con líneas definidas y blancos brillantes, crea un contraste moderno y audaz, pero combina igualmente bien con estilos de época y espacios tradicionales para transmitir un toque de nostalgia.
  • La válvula de presión balanceada Monitor mantiene el agua a una temperatura segura dentro de los +/-3º F (+/-1.6º C) y así, protege contra cambios repentinos en la presión del agua fría o caliente.
  • Juego de terminación solamente, se debe pedir la válvula universal MultiChoice por separado para completar la unidad
  • Cumplimiento con la ADA
Información especial
Imagen de advertencia
ADVERTENCIA de la Proposición 65 de California
Technology and Special Features
Cumplimiento con la ADA
Válvula universal MultiChoice®
Monitor®
Documentos y especificaciones
Soporte para productos, repuestos y especificaciones técnicas
Ver especificaciones técnicas
Ver hoja de mantenimiento e instalación
Ver diagrama de repuestos y accesorios
Registrar su producto
Recursos
Archivos de diseño
Información de instalación
Overall Height (in.) :
12
Voltaje:
0
Tipo de válvula:
Cartucho con equilibrio de presión de función única

SOPORTE PARA LA INSTALACIÓN

¿Necesita ayuda con la instalación? Busque instaladores locales de Delta® Obtenga cotizaciones. Lea reseñas.

IR
Escriba un código postal válido.
Mike y Hanna
Miniatura del logotipo de Delta

¿Necesita ayuda con la instalación? ¡Mike y Hannah están aquí para ayudar! Reciba consejos de los profesionales para todo, desde la instalación hasta el cuidado del producto.

Explorar videos
RESEÑAS
Rated 5 out of 5 by from Complete look Finishes the sleek, sophisticated look
Date published: 2023-03-29
Rated 5 out of 5 by from Love the Matte black! beautiful matte black trim!
Date published: 2022-08-21
Rated 5 out of 5 by from Good pick Works great and looks amazing
Date published: 2022-03-27
Rated 3 out of 5 by from Delta Shower assembly This is a second hand held shower in our home. I prefer the Moen brand to this shower assembly. The handle creaks a little when adjusted.
Date published: 2021-07-13
Rated 5 out of 5 by from Good product Nice product and works well
Date published: 2020-09-13
Rated 5 out of 5 by from Function and beauty Loved this modern simple fixture. Bought three and would do so again. The color has held up without any variation. Great buy
Date published: 2020-01-28
Rated 5 out of 5 by from Delta Ashlyn [This review was collected as part of a promotion.] Used for a bathroom remodel. Installed easily, works perfectly, looks great and client loves it. Of course they do - it's a Delta!
Date published: 2019-12-11
Rated 5 out of 5 by from Project Manager I'm impressed with the quality of this fixture, it is well thought out and designed.
Date published: 2019-11-05
  • y_2024, m_11, d_21, h_6
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.42
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_11
  • loc_en_US, sid_T14264-LHD, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_deltafaucet
  • bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0
  • CLOUD, getReviews, 9ms
  • reviews, product
Preguntas y respuestas

Which R10000 will work

Thanks for your feedback on my earlier question. I will order the T14264-SSLHD and 58470-SS as recommended. Will a R10000-UNWSHF work for this combination? It was purchased for a different configuration and I'm wondering if I need to return it and order something else. Thanks!
Asked by: Time 2 remodel
Hi Time 2 remodel, Thank you for your question! The R10000-UNWSHF will work with the T14264-SSLHD and 58470-SS. Best regards, Brandis
Answered by: DeltaFaucet7
Date published: 2024-03-28

What is the GPM flow rate on this model (not in specs)

Asked by: Chloe
Hi Chloe, Thank you for your question! The model T14264-LHD (less showerhead) does not provide the gallons per minute because it does not include a shower head. The gallons per minute depends the shower head you choose. Best regards, Brandis
Answered by: DeltaFaucet7
Date published: 2024-03-28

What do i need for a complete remodel set-up if purchasing the 58470-SS?

We are remodeling our bathroom and I am considering the H2oKinetic In2ition 58470-SS Shower Head. We have ordered the Ashlyn faucette and I would like to understand what to order to complete the set-up. 1.) If I order the T11864-SS I assume I'll also need to order the R1000. Is there anything else I will need? 2.) If I order the T14264-SSLHD I assume I'll also need to order the R11000. Is there anything else I will need? 3.) I don't understand the difference between the T11864-SS and the T14264-SSLHD basic shower trim. It seems they are different, but I don't understand the difference between the two (besides the inclusive items).
Asked by: Time 2 remodel
Hi Time 2 remodel, Thank you for your question. The T14264-SSLHD requires an R10000 rough-in valve. The valve and shower head are the only other things you will need to purchase with this trim for a shower-only installation. The T11864-SS is a 3-Setting Diverter Trim and does not control the temperature or flow of water. It works in conjunction with a 14, 17, or 17T series valve and will divert water between two components. This unit would not be required in your installation unless you wish to add an additional shower head, hand shower, or body sprays. This trim would require an R11000 valve. Best regards, Jon
Answered by: DeltaFaucet3
Date published: 2024-03-28

Just finished a bathroom remodel and noticed that the shower handle is extremely wobbly. Is this a quick fix I can do myself or do I need to call the contractor back to fix it? I'd prefer to fix it myself.

Asked by: Katy
Thank you for your question, Katy! This repair is very simple and often does not require the use of a professional. Your handle is held onto the stem of the cartridge with a set screw which can be tightened with a 3/32" Allen wrench, part number RP26853. https://media.deltafaucet.com/PartsDiagram/DPD-B-T14064_A.pdf Best regards, Edward
Answered by: DeltaFaucet234
Date published: 2024-03-28

Will this trim kit work with 58472 shower head?

Asked by: Cricket
Hello Cricket! Thank you for your question and we are happy to help. We apologize for this information not being readily available to you. The Delta Universal Showering H2Okinetic® In2ition® 4-Setting Two-In-One Shower In Matte Black MODEL#: 58472-BL will work with the Delta Ashlyn® Monitor® 14 Series Shower Trim - Less Head In Matte Black MODEL#: T14264-BLLHD. With any further questions or concerns, please do not hesitate to reach out to us directly. Thank you for being a loyal Delta Faucet customer. Best Regards, Carrie
Answered by: Delta7
Date published: 2024-03-28

We are remodeling our master bath. I plan to use a delta brushed nickel shower head but most of the trim doesn't seem to be available in that finish. How close is the stainless to brushed nickel?

Asked by: Joanne
Hi Joanne, Thank you for contacting us at Delta Faucet! Please accept our sincere apology for the inconvenience you are experiencing. Here is what we can do to resolve your issue for you. This Delta Faucet stainless steel finish is very similar to brushed nickel and to the naked eye there may not be much difference but there is a slight difference in tone. Please contact us directly by phone at 1-800-345-3358 or email at customerservice@deltafaucet.com if further assistance is needed at this time.   We appreciate your loyalty to Delta Faucet Company. Best Regards, Tim Digital Communications Specialist (800) 345-3358 customerservice@deltafaucet.com
Answered by: Customer Service
Date published: 2024-03-28

I’m confused about which valve to order for this. Can you tell me the model number?

Asked by: Crlw1994
Hi Crlw1994, Thanks so much for contacting Delta Faucet Company! The T14264-BLLHD requires the universal rough end valve, R10000-UNWS to be purchased separately. https://www.deltafaucet.com/bathroom/product/R10000-UNWS.html Please contact us directly if you have any questions or need additional assistance. Best Regards, Nicole Digital Communications Specialist
Answered by: Customer Service
Date published: 2024-03-28

Will shower trim kit Ashlyn #T14064-SS work with delta valve# ASSE 1016.?

Asked by: Harry
Hello Harry, Thank you for your question about the Delta Faucet model T14264-SSLHD ASHLYN® Monitor® 14 Series Shower Trim - Less Head. I apologize for any difficulty finding this information. We are happy to help! This trim kit and the T14064-SS trim kit will fit a Delta MultiChoice R10000 valve rough-in. https://www.deltafaucet.com/bathroom/product/R10000-UN.html Please reach out at customerservice@deltafaucet.com or 1-800-345-DELTA if you have any questions or need additional assistance. Thank you for being a loyal Delta Faucet customer. Best regards, Bryan
Answered by: Delta Faucet
Date published: 2024-03-28
